Mouser Electronics, the authorized global distributor with the newest electronic components and industrial automation products, is now shipping the new UCC33420-Q1 automotive-qualified 1.5W isolated DC/DC module from Texas Instruments. The UCC33420-Q1 enables a distributed power architecture, helping engineers meet functional safety requirements by avoiding single-point failures, enabling compact, high-performance, and reliable designs for automotive, industrial, and data center applications.
The Texas Instruments UCC33420-Q1 DC/DC module, available from Mouser, integrates proprietary IsoShield technology to deliver industry-leading power density. IsoShield technology co-packages a high-performance planar transformer and an isolated power stage, offering functional, basic, and reinforced isolation capabilities that enable distributed power architecture and achieve safety requirements to avoid single-point failures. The result is an advancement in packaging that shrinks solution size by as much as 70%, while delivering up to 1.5W of compact, high-performance power for applications that require reliable, reinforced isolation. The UCC33420-Q1 features a 3kVRMS isolation rating, providing efficient, isolated power to circuits that require a bias supply with a well-regulated output voltage.
The device also has an enable pin, a fault reporting mechanism, and a regulated 5.0V output with a selectable headroom of 5.5V. This device comes in a miniaturized VSON package with a 1 mm height (typical). With protection features that enhance system robustness, this device helps engineers maximize power density while reducing material costs and design time across any power application.
